ST4000 Articulated Tandem Road Roller

Equipped with famous brand power, quality assurance, superior performance.

Still deciding? Get samples first,  Contact US !

Tag list

  • Product Description
  • The ST4000 Articulated Tandem Road Roller is a robust 4-ton dual-drum compactor engineered for high-performance asphalt and base material compaction in road construction and maintenance projects. With a hydraulic drive system powering both drums, the machine provides excellent traction, smooth travel, and reliable compaction results across varied job conditions. Its articulated steering system ensures superior maneuverability, while interlocked dual control levers offer intuitive operation and precise control. The One-Touch Simultaneous Front and Rear Drum Vibration System delivers uniform compaction efficiency, complemented by a One-Touch Electronically Controlled Intermittent Pressure Spray System that prevents asphalt adhesion and conserves water. For extended working hours, the LED front and rear work lamps enhance safety and visibility in low-light environments. Combining power, precision, and operator comfort, the ST300 is an ideal choice for contractors handling medium-scale paving and infrastructure projects.



    Typical Applications

    ●Asphalt paving and compaction for municipal, highway, and rural road projects
    ●Medium-scale parking lots, industrial yards, and commercial driveways
    ●Base and sub-base layer compaction before asphalt surfacing
    ●Airport runways, sports courts, and urban development projects
    ●Road maintenance and repair operations requiring high mobility and consistent finish



    Product Key Features
    ●Equipped with famous brand power, quality assurance, superior performance.
    ●Ergonomic design, wide field of vision, beautiful and stylish.
    ●Equipped with renowned hydraulic variable displacement pump and fixed displacement motor ensure stepless speed variation, enabling smooth forward and backward movement.
    ●LED Display control panel is fully functional, one-key operation
    ●Equipped with front and rear lighting & warning lights, convenient for operation at night.
    ●The steel wheel is equipped with an outline light which is easy to operate, safe and efficient.
    ●The product has obtained CE certification and the design of the Red Star Award.



















    Main technical parameters

    ST4000 Technical parameter

    Model

    Unit

    ST4000

    Weight

    Operating weight

    kg

    4000

    Static line load

    n/cm

    135/120

    Size

    Working width

    mm

    1370

    Overall length

    mm

    2580/2480

    Overall height

    mm

    2000/2670

    Outside the turning radius

    mm

    2750/4130

    Drum width

    mm

    1200

    Drum diameter

    mm

    720

    Wheel base

    mm

    1720

    Drive

    Engine brand



    CHANGCHAI

    YANMAR

    KUBOTA

    Engine model



    ZN390B

    3TNV88

    V1505

    Engine type



    Water-cooled four-stroke diesel engine

    Number of cylinders



    3

    3

    4

    Output Power

    kw

    28.5

    28.1

    26.1

    Rotating speed

    rpm

    2600

    3000

    3000

    Electrical equipment

    V

    12

    Driving mode



    Dual wheels are driven by a variable displacement piston pump to achieve infinitely variable speed control l

    Walking characteristics

    Speed

    km/h

    0-10

    Theoretical climbing ability

    %

    30/40

    Brake

    Service brake



    Variable displacement piston pump

    Steering

    Steering method



    Hydraulic steering

    Vibration system

    Vibrating drum



    Front/rear

    Front + rear

    Drive form



    Hydraulic motor

    vibration frequency

    hz

    65

    Vibration amplitude

    mm

    0.5

    Exciting force

    kn

    50/50

    2*50

    Sprinkler system

    Form



    Intermittent pressure spray

    Capacity

    Fuel capacity

    L

    42

    Hydraulic oil capacity

    L

    42

    Water tank capacity

    L

    180
